Optical Module

• Static photometer with photometric range (340-670)
• 8 interference filters 340, 405, 450, 505, 546, 578,
• 600 and 670 nm
• Silicon photodiode detectors
• Photometric Range from 0 to 3.0 OD
• Quartz Halogen Lamp of 12V, 20W

Measuring Module

• Unique Triple Cuvette System
• 18 µl Flow cell
• 10 mm Square Cuvette
• 6 mm Round Glass Tube with Adaptor
  Peltier Temperature Control: 20°C-40°C in steps of 1°C
  Peristaltic Pump
  Minimum Aspiration Volume 200 µl

Analysis Modes

• 1-point linear Rate A non-linear
• 2-point linear 1-point sample blank linear
• 1-point non-linear 1-point sample blank non-linear
• 2-point non-linear Absorbance
• Rate A linear Coagulation

Memory

• 200 User Defined Test Programs
• 1000 Test Result
• Reagent Blank
• 3 Levels of QC

Result Recall

• : Collated Reports by Date, ID, Date & ID
• Test & Date wise and Patient Demographics

Built-in QC

• Daily and Monthly monitoring for 3 Levels
• Levy – Jenning QC Graphs

Display

• High Resolution Graphics LCD with backlight.
• View Area: 120 x 92 mm

Keyboard

• 41 Multifunction Keys and 6 dynamic keys

Printer

• In Built High Resolution Graphic Thermal Printer

Interface

• USB connectivity to PC
• Direct printer connectivity through USB port
• Port for External keyboard

Power

• External Universal SMPS adapter
• 18V DC, 70W, 115/230V AC (± 10%), 50/60 Hz

Size(mm)

• 205 (H) x 450 (W) x 300(D)

Weight

• Approx. 7 Kgs.

Optional Accessories

• External 16 Position Dry Block Incubator
